Product Application:
BMM micro high speed hydraulic motor is widely used in various construction machinery, agricultural machinery, transportation, machine manufacturing and other departments, such as hydraulic press, conveyor, manipulator, injection molding machine, harvester, tubing pliers, manipulator, lifting crane and other mechanical equipment.
Characteristic Features:
Compact structure, light weight, high efficiency, high speed
The shaft seal has high pressure and can be used in series or parallel
Advanced structure design, high power density
Main Technical Parameters
Displacement (ml/r) | 8 | 12.5 | 20 | 32 | 40 | 50 | |
Max.Flow( lpm ) | Cont | 16 | 20 | 20 | 20 | 20 | 20 |
Int | 20 | 25 | 25 | 25 | 25 | 25 | |
Max.Speed(RPM) | Cont | 1550 | 1550 | 630 | 241 | 500 | 400 |
Int | 1940 | 1940 | 800 | 355 | 630 | 500 | |
Max.Pressure (MPa) | Cont | 10 | 10 | 10 | 16 | 9 | 7 |
Int | 14 | 14 | 14 | 25 | 14 | 14 | |
Max. Torque(N-M) | Coni | 11 | 16 | 40 | 1411 | 45 | 46 |
Int | 15 | 23 | 57 | 2217 | 70 | 88 | |
